Sony SDM-S71 - Manual (Page 103)

i
Appendix
Preset mode timing table
SDM-S51
SDM-S71/S81
No. Resolution
(dots ×
lines)
Horizontal
Frequency Vertical
Frequency Graphics
Mode
1 640
× 480
31.5 kHz 60 Hz VGA-G
2 640
× 480
37.5 kHz 75 Hz EVGA
3 720
× 400
31.5 kHz 70 Hz VGA-Text
4 800
× 600
35.2 kHz 56 Hz VESA
5 800
× 600
37.9 kHz 60 Hz SVGA
6 800
× 600
48.1 kHz 72 Hz VESA
7 800
× 600
46.9 kHz 75 Hz ESVGA
8 832
× 624
49.7 kHz 75 Hz Macintosh 16"
Color
9 1024
× 768
48.4 kHz 60 Hz VESA
10 1024
× 768
56.5 kHz 70 Hz VESA
11 1024
× 768
60.0 kHz 75 Hz EUVGA
12 1024
× 768
60.2 kHz 75 Hz Macintosh 19"
Color
No. Resolution
(dots ×
lines)
Horizontal
Frequency Vertical
Frequency Graphics
Mode
1 640
× 480
31.5 kHz 60 Hz VGA-G
2 640
× 480
37.5 kHz 75 Hz EVGA
3 640 × 480 43.3 kHz 85 Hz VESA
4 720 × 400 31.5 kHz 70 Hz VGA-Text
5 800 × 600 37.9 kHz 60 Hz SVGA
6 800 × 600 46.9 kHz 75 Hz ESVGA
7 800 × 600 53.7 kHz 85 Hz VESA
8 832 × 624 49.7 kHz 75 Hz Macintosh 16"
Color
9 1024
× 768
48.4 kHz 60 Hz VESA
10 1024
× 768
60.0 kHz 75 Hz EUVGA
11 1024
× 768
68.7 kHz 85 Hz VESA
12 1024 × 768 60.2 kHz 75 Hz Macintosh 19"
Color
13 1152
× 870
68.7 kHz 75 Hz Macintosh
14 1280
× 1024
64.0 kHz 60 Hz VESA
15 1280
× 1024
80.0 kHz 75 Hz VESA
16 1280
× 1024
91.1 kHz 85 Hz VESA
