1 mounting procedures – ATN NVM14 User Manual
Page 24
3-2
3.1 MOUNTING PROCEDURES
CAUTION
It is recommended that the eyecup be replaced with the
eyeguard during weapon-mounted use.
NOTE
The ATN NVM-14 is not a weapon sight, however, it can be
used in conjunction with a collimated dot sight or laser aiming
device.
A. MOUNTING THE ATN NVM-14 TO THE WEAPON
To mount the ATN NVM-14 perform the following:
1.Loosen the clamping knob on the weapon mount. Position the
monocular mount on the weapon’s mounting rail, adjust the
fore/aft position of the monocular as necessary by loosening
the clamping knob and repositioning the weapon mount on
the rail. Tighten by turning the clamping knob (see figure 3-1).
Figure 3-1
Attaching Weapon Mount to Weapon
