Identifying parts
See the pages in parentheses for details of
operation.
Camera
A Shutter button (26)
B Zoom (W/T) lever (27, 30)
C Stereo microphone
D
(Playback) button (31)
E POWER button/POWER lamp
F Flash (28)
G Lens
H Self-timer lamp (27, 30)/AF illuminator
(78)
I Lens cover
A LCD screen/Touch panel (21, 22)
B Mode switch (25, 29)
C Hook for wrist strap/Grip
D Speaker
E Battery insertion slot
F Multi connector
G Access lamp
H “Memory Stick Duo” slot
I Battery eject lever
J Battery/“Memory Stick Duo” cover
K Tripod receptacle
• Use a tripod with a screw less than 5.5 mm
(7/32 inch) long. Otherwise, you cannot
firmly secure the camera, and damage to the
camera may occur.
Bottom
