Locating Controls and Ports

17

Removing Rubber Tab

Gently pull the rubber tab away from the computer to find the Ethernet port and phone
line jack.

Bottom

1

Docking station connector

5

Air vent

2

Battery Unlock/Lock switch 6

Reset switch

3

Battery Unlock switch

7

Ventilation fan

4

Air vent

Rubber tab
