66 US
Specifications
Amplifier Section
U.S.models:
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
(FTC)
Front L + Front R:
With 3 ohms loads, both
channels driven, from 180
- 20,000 Hz; rated 60 watts
per channel minimum
RMS power, with no more
than 1% total harmonic
distortion from 250 milli
watts to rated output.
Other models:
POWER OUTPUT (rated)
Front L/Front R:
108 W + 108 W (at 3 ohms,
1 kHz, 1% THD)
POWER OUTPUT (reference)
Front L/Front R/Center/Surround L/Surround R:
167 W (per channel at
3 ohms, 1 kHz)
Subwoofer: 165 W (at 3 ohms, 80 Hz)
Inputs (Analog)
AUDIO (AUDIO IN)
Sensitivity: 450/250 mV
Inputs (Digital)
SAT/CABLE (COAXIAL)
TV (Audio Return Channel/OPTICAL)
Supported formats: LPCM
2CH (up to 48 kHz), Dolby
Digital, DTS
HDMI (IN 1)/HDMI (IN 2)
Supported formats: LPCM
2CH (up to 96 kHz), Dolby
Digital, DTS
Video Section
Outputs VIDEO: 1 Vp-p 75 ohms
COMPONENT:
Y: 1 Vp-p 75 ohms
P B , P R : 0.7 Vp-p
75 ohms
HDMI Section
Connector Type A (19pin)
BD/DVD/Super Audio CD/CD System
Signal format system
U.S. and Canada models: NTSC
Other models:
NTSC/PAL
USB Section
(USB) port: Type A (For connecting
USB memory, memory
card reader, digital still
camera, and digital video
camera)
LAN Section
LAN (100) terminal 100BASE-TX Terminal
Wireless LAN Section
Standards Compliance IEEE 802.11 b/g/n
Frequency and Channel 2.4 GHz - 2.4835 GHz
[CH1 -11]
FM Tuner Section
System PLL quartz-locked digital
synthesizer
Tuning range
U.S. and Canada models: 87.5 MHz - 108.0 MHz
(100 kHz step)
Other models: 87.5 MHz - 108.0 MHz (50
kHz step)
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals 75 ohms, unbalanced
Speakers
Front/Surround (SS-TSB106)
Dimensions (approx.) 96 mm × 245 mm × 96 mm
(3
7 /
8
in × 9 3 /
4
in × 3 7 /
8
in)
(w/h/d)
Mass (approx.) 0.6 kg (1 lb 6 oz)
Center (SS-CTB103)
Dimensions (approx.) 315 mm × 59 mm × 53 mm
(12
1 /
2
in × 2 3 /
8
in ×
2 1 /
8
in) (w/h/d)
Mass (approx.) 0.4 kg (15 oz)
Subwoofer (SS-WSB104)
Dimensions (approx.) 380 mm × 330 mm × 191
mm (15 in × 13 in ×
7
5 /
8
in) (w/h/d)
Mass (approx.) 6.3 kg (13 lb 15 oz)
General
Power requirements
U.S. and Canada models: 120 V AC, 60 Hz
Other models:
110 V - 240 V AC,
50/60 Hz
Power consumption On: 170 W
Standby: 0.3 W (at the
Power Saving mode)
Dimensions (approx.) 430 mm × 75 mm × 320
mm (17 in × 3 in ×
12
5 /
8
in) (w/h/d) incl.
projecting parts
Mass (approx.) 4.1 kg (9 lb 1 oz)
