MegaRAID Express 500 Hardware Guide 80
68-Pin High Density Connectors, Continued
Cable Assembly for Internal Wide SCSI Devices The cable assembly for connecting internal
wide SCSI devices is shown below:
pin 1
pin 1
pin 1
Connectors: 68 position plug (male)
A M P - 7 8 6 0 9 0 - 7
Cable: Flat Ribbon or Twisted-Pair Flat Cable
68 Conductor 0.025 Centerline
3 0 A W G
Cont’d
