American Megatrends MegaRAID Express 500 User Manual
Page 5
Preface
v
Table of Contents,
Continued
Hardware Installation ............................ 51
Installation Steps .............................................................52
Step 1 Unpack .................................................................53
Step 2 Power Down.........................................................53
Step 3 Configure Motherboard........................................53
Step 4 Install Cache Memory ..........................................54
Step 5 Set Jumpers ..........................................................56
MegaRAID Express 500 Card Layout ............................56
Step 6 Set Termination....................................................59
SCSI Termination............................................................60
Step 7 Install MegaRAID Express 500 ...........................63
Step 8 Connect SCSI Cables ...........................................64
Step 9 Set Target IDs ......................................................65
Device Identification on MegaRAID Express 500..........66
Step 10 Power Up ...........................................................67
Step 11 Run MegaRAID BIOS Setup .............................67
Step 12 Install the Operating System Driver ...................68
Troubleshooting .................................... 71
BIOS Boot Error Messages.............................................73
Other BIOS Error Messages............................................75
DOS ASPI Driver Error Messages..................................76
Other Potential Problems ................................................77
SCSI Cables and Connectors ............... 79
SCSI Connectors .............................................................79
68-Pin High Density SCSI Internal Connector................79
High-Density 68-Pin SCSI Connector Pinout .................85
68-Pin Connector Pinout for LVD SCSI .........................87
B Audible Warnings ......................................... 89
Glossary ............................................................ 91
Index ................................................................ 101
