Introduction
1-2
Copyright © 2001-2003. All rights reserved.
ARM DUI 0163B
1.1
About the Integrator/IM-AD1
The Integrator/IM-AD1 is an interface module that is designed to be used in conjunction
with the Integrator/LM-XCV600E+ or LM-EP20K600E+ and future compatible logic
modules. It provides several standard automotive and industrial interfaces, and can be
used for:
•
proof of concept and application development
•
benchmarking
•
PrimeCell development and testing
•
SoC prototyping.
The interface module is designed to be mounted on top of the logic module and provides
connectivity for peripherals in the logic module FPGA.
Figure 1-1 on page 1-3 shows the layout of the IM-AD1 and identifies the connectors.
The IM-AD1 can be used to implement additional peripherals to aid software
development, for example additional timers or a vector interrupt controller. The
IM-AD1 product consists of:
•
a fully populated PCB
•
example bit files for an LM
•
example driver source code
•
this documentation.
