Operation
11 F232123
Machine Familiarization Guide
The machine familiarization guide in Figure 2
provides front and rear views of the washer-extractor
and identifies the major operational features of the
machine.
Figure 2
P005I
1 Emergency Stop Button 8 Side Panel
2 Supply Valve Box 9 Front Panel
3 Supply Dispenser 10 Rub Rail
4 Door Handle 11 Shell Front
5 Door Box 12 Door Hinge
6 Door Latch Extension Arm 13 Door
7 Door Latch 14 Control Module
WARNING
MACHINE MAY BE HOT
AND CAUSE BURNS
ATTEMPT NO ENTRY UNTIL BASKET HAS STOPPED SERIOUS INJURY MAY RESU LT
R
Door Unlock
Press and Hold
Emergenc y Stop
Up Down Start Stop
P005I
1
2
3
4
5
6
7
8 9
10
11
12
13
14
