FPC 8059 User’s Manual
C h a p t e r 3
Windows CE.Net
3.1 Survey Form
Compact Flash Card e 32MB ~ 2GB
System Memory Support e 256MB ~ 1GB
Multiple I/O e Parallel Port
e 3 x UARTs compliant Serial Ports
USB 2.0 e 2 x USB 1.1
Keyboard & Mouse e PS/2 Keyboard & Mouse
e USB Keyboard & Mouse
Display (MS Flat) e 320 x 240
Ethernet e Realtek 8139x/810x 10/100M
Audio e Line-out
Touch Screen e 5-wire Resistive type
3.2 Calibrate Touch Screen
This image includes a Touch Screen on COM3. To calibrate it,
do the following steps:
1. Start\Programs\PenMount TouchPanel\Calibration
2. 3 types of calibration mode selection (4/9/16 points)
12 Appendix
