2 Introduction
FPC 8059 User’s Manual
1.2 Specifications
1.2.1 Main CPU board
f CPU: AMD LX800 500MHz
f System Chipset: AMD LX + CS5536AD
f BIOS: Phoenix-Award 4Mbit with RPL/PXE Ethernet Boot
ROM, Smartview and customer CMOS backup.
f System Memory: One 184-pin DDR DIMM
Maximum up to 1GB
1.2.2 I/O System
f Standard I/O:
− 2 x serial ports (1 x RS-232, 1 x RS-232/422/485)
− 2 x USB Ports 2.0 compliant
f Ethernet:
Equipped with 1 x RJ-45 for 10/100 base-T
f Audio:
Realtek AC’97 codec audio (Line-out)
f Expansion:
Equipped with 1 x Mini-PCI & 1 x PC/104
f Compact Flash Socket:
One Compact Flash Type II Socket
