Aussie 8462 User Manual

Page 23

background image

1

2

3

4

5

6

7

8

9

10

Grid

Ceramic Briquette Tray

Burner

Cotter Pin

Handle

Spacer, Handle

Bolt, M6x80

Grill Body Assy.

Screw, #8x1/2

Regulator/ Hose

QTY.

2

2

3 or 4

3 or 4

1

2

2

1

2

1

3-BURNER PART

NUMBER

03.5023.00

03.6095.03

03.6039.00

03.5012.00

03.6261.00

03.6023.00

03.6262.00

03.6263.00

03.6010.00

03.5854.00

4-BURNER PART

NUMBER

03.6016.00

03.6095.04

03.6039.00

03.5012.00

03.6261.01

03.6023.00

03.6262.00

03.6263.01

03.6010.00

03.5854.00

PART/DESCRIPTION

11

Panel, Bottom Body

1

03.5998.00

03.5999.00

12

Foil Pan

1

03.6011.00

03.6011.00

13

Grease Tray

1

03.6012.00

03.6012.00

14

15

16

17

18

19

Side Table

Screw, Flat Head M4x12 BK

Nut Black M4

Bolt, Black M4x10

Wheel Assembly

Axle

2

4

4

4

2

1

03.6264.00

03.6265.00

03.6266.00

03.6267.00

03.5994.00

03.6093.00

03.6264.00

03.6265.00

03.6266.00

03.6267.00

03.5994.00

03.6093.00

23
