14

Chapter 1

Bottom View

#

Item

Description

1

Battery release latches

Release the battery for removal

2

Optical drive bay release
latch

Releases the optical drive for removal

3

Cooling fan

Helps keep the computer cool
Note: Do not cover or obstruct the opening of the fan.

4

Optical drive bay

Houses the computer's optical drive.

5

Wireless LAN bay

Houses the computer's wireless LAN

6

Hard disk bay

Houses the computer's hard disk (secured by a screw)

7

Battery bay

Houses the computer's battery pack

8

Memory compartment

Houses the computer's main memory

#
