8
Installing the graphics card
1 Turn off the computer, monitor, and other peripheral devices.
2 Unplug the computer’s power cord and disconnect all cables from the
back of your computer.
3 Remove the computer cover.
If necessary, consult your computer’s manual for help in removing the
cover.
4 Unscrew or unfasten and remove any existing graphics card from
your computer.
Note: If your computer has an on-board graphics capability, you may
need to disable it on the motherboard. For more information, see your
computer documentation.
5 Locate the appropriate slot and, if necessary, remove the metal back-
plate cover.
6 Align your ATI graphics card with the slot and press it in firmly until
the card is fully seated.
3 6-pin Power Cable Connector
4 6-pin Power Connection
5 Power connector to Graphics Card
6 Power connector to Power Supply
L WARNING - Wait approximately 20 seconds after unplugging the
power cord before disconnecting a peripheral or removing a
component from the motherboard to avoid possible damage to the
motherboard.
L WARNING - Remember to discharge your body’s static electricity by
touching the power supply or the metal surface of the computer
chassis.
