– 5
Notes about the ingredients
(REACH)
You will find current information about
the ingredients at:
www.kaercher.com/REACH
 Read the oil level display when the
device is not running. The oil level
must be above the two pointers.
 Unscrew the fastening screws of
the device hood; remove the device
hood.
 Cut off tip of oil container cover
 Fasten the device hood.
 Mount the nozzle on the spray pipe
(markings on the adjustment ring at
the top).
 Connect ray tube to hand spray gun
 Lever out the safety clip of the
handspray gun using a screw-driver
(Picture A).
 Place the hand-spray gun upside
down and insert the end of the high
pressure hose till the end. Ensure
that the lose disc falls right below on
the hose end (Picture B).
 Press the safety clip back into the
hand-spray gun. The hose can be
pulled out max. 1 mm if it has been
installed correctly. Otherwise, it
means the disc has been installed
wrongly (picture C).
 Loosen the clamps of the pushing
handle.
 Adjust the handle to the desired
height.
 Tighten the clamps of the pushing
handle.
 Fasten the high pressure hose to
the high pressure connection.
ṇ Danger
Danger of injury by electric shock.
The appliance may only be connected
to an electrical supply which has been
installed in accordance with IEC
60364.
The voltage indicated on the type plate
must correspond to the voltage of the
electrical source.
The minimum fuse rating required at
the socket outlet is (see technical
specifications).
The appliance should always be con-
nected to the electrical mains using a
Environmental protection
The packaging material can
be recycled. Please do not
throw the packaging materi-
al into household waste;
please send it for recycling.
Old appliances contain
valuable materials that can
be recycled; these should
be sent for recycling. Batter-
ies, oil, and similar sub-
stances must not enter the
environment. Please dis-
pose of your old appliances
using appropriate collection
systems.
Please do not release engine oil, fuel
oil, diesel and petrol into the environ-
ment Protect the ground and dispose
of used oil in an environmentally-
clean manner.
Before Startup
Check oil level
Activate deaeration of oil con-
tainer
Attaching the Accessories
Start up
Electrical connection
7 EN
