– 5
While reducing the water supply/quantity
regulation at the pump head, the over-
flow valve opens and part of the water
flows back to the pump suck side.
If the lever on the trigger gun is re-
leased the pressure switch turns off the
pump, the high pressure jet is stopped.
If the lever is pulled the pump is turned
on again.
The overflow valve and pressure
switch are set and sealed at the facto-
ry. Setting only by customer service.
Notes about the ingredients
(REACH)
You will find current information about
the ingredients at:
www.kaercher.com/REACH
–
Check the contents of the pack be-
fore unpacking.
–
In case of transport damage inform
vendor immediately
 Read the oil level display when the
device is not running. The oil level
must be above the two pointers.
 Unscrew the fastening screws of the
device hood; remove the device hood.
 Cut off tip of oil container cover
 Fasten the device hood.
 Mount the nozzle on the spray pipe
(markings on the adjustment ring at
the top).
 Install spray pipe on the hand-spray
gun with pressure and volume reg-
ulation.
 Lock in the cable hook in the side-
hole on the handle.
 Fasten the high pressure hose to
the high pressure connection.
ṇ
Danger
Danger of injury by electric shock.
The appliance may only be connected to
an electrical supply which has been in-
stalled in accordance with IEC 60364.
The voltage indicated on the type plate
must correspond to the voltage of the
electrical source.
The minimum fuse rating required at
the socket outlet is (see technical
specifications).
Overflow valve with pressure
switch
Environmental protection
The packaging material can
be recycled. Please do not
throw the packaging materi-
al into household waste;
please send it for recycling.
Old appliances contain
valuable materials that can
be recycled; these should
be sent for recycling. Batter-
ies, oil, and similar sub-
stances must not enter the
environment. Please dis-
pose of your old appliances
using appropriate collection
systems.
Please do not release engine oil, fuel
oil, diesel and petrol into the environ-
ment Protect the ground and dispose
of used oil in an environmentally-
clean manner.
Before Startup
Unpacking
Check oil level
Activate deaeration of oil container
Attaching the Accessories
Start up
Electrical connection
7 EN
