6 English
 STEP 1:
Insert wheels into the body of the unit.
 STEP 2:
Insert the steering rollers and lock
them.
 STEP 3:
Fix the VELCRO
® fastener to the ap-
pliance.
 STEP 4:
Install the supplied connector to the
unit’s water inlet.
Note: Never attach the garden hose
connector to the unit’s water inlet!
 STEP 5:
A Pull out the locking slide of the trigger
gun handle.
B Insert the small end of the high pres-
sure hose into place.
C Push the locking slide back into the
trigger gun to lock the hose in posi-
tion.
 STEP 1:
Connect the high pressure hose to
the unit’s high pressure outlet.
 STEP 2:
Insert the spray wand of your choice
into the trigger gun. Press in against
the spring tension and twist into
locked position.
 STEP 3:
Screw the supplied garden hose con-
nector on to the end of your garden
hose.
ASSEMBLY INSTRUCTIONS OPERATING
INSTRUCTIONS
