14
English
Î Remove the combs and replace them.
To do this, slide the inlet combs on the
narrow rails and the outlet combs on the
wider rails.
Î Pull out all dirt particles from the suction
nozzles; do not push them in.
Î Loosen the fastening screws of the hold-
er for the guide rails.
Î Dismantle the guide rails.
Î Insert the guide rails in reverse se-
quence. Ensure that they sit properly.
Î Loosen the union joint. Remove nozzle,
washer and sieve.
Î Clean the nozzle or insert a new nozzle
in the union joint.
Î Insert washer and sieve and tighten the
union joint by hand.
Î Unscrew the pad with a screw-driver and
replace it.
ƽ
Danger
Risk of injury! Do not drive over slopes great-
er than 5°. Never transport the machine over
the travellator/ escalator.
Î
Lock the rear wheels.
Î Secure the machine with clamping belts
and ropes so that it doesn't slip off.
Replacing the combs
Cleaning the suction nozzles
Replacing the guide rails
Check nozzles and filters for detergents
Replacing the pad
Transport
