– 4
1 Suction head
2 Lever for filter cleaning
3 Handle
4 Connection nozzle
5 Parking brake
6 Swivel casters
7 Operator console
8 Lever for unlocking the waste container
9 Waste container (optional)
10 Cable storage hook
11 Holder for vacuum pipe
12 Filter chamber
13 Manometer
14 Silencer
15 Diffuser
