Asus K8V-MX - Manual (Page 9)

ix
K8V-MX Specifications Summary
CPU
Chipset
System bus
Memory
Expansion slots
VGA
Storage
Audio
LAN
USB 2.0
Rear panel I/O ports
Socket 754 for AMD Athlon™ 64 processor with 800 MHz
FSB frequency and built-in L2 cache up to 1 MB
AMD Athlon™ 64 architecture supports simultaneous 32-bit
and 64-bit computing
VIA K8M800
VIA VT8237R
1600MT/s
2 x 184-pin DDR DIMM sockets for up to 2 GB unbuffered
ECC, non-ECC DDR 400/333/266 DRAM memory
1 x AGP8X
3 x PCI
Integrated Graphics
2 x Serial ATA, RAID 0, RAID 1, JBOD
2 x UltraDMA 133/100/66
ADI AD1888 SoundMAX 6-channel audio CODEC
S/PDIF out interface
Integrated 10/100 Mbps LAN controller in the southbridge
with Realtek RTL8201CL LAN PHY
Supports up to 8 USB 2.0 ports
1 x Parallel port
1 x Serial port
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x VGA port
1 x Audio I/O port
1 x LAN (RJ-45) port
4 x USB 2.0 ports
(Continued on the next page)
