Rev 08/09 ©2009 ATTO Technology, Inc. Specifications subject to change without notice
Technical Specification
Power Behind the Storage Power Behind the Storage Power Behind the Storage Power Behind the Storage
For More Information:
www.ATTOTech.com
or to Purchase:
www.ATTOStore.com
(716) 691-1999
Hardware Specifications
Fibre Channel Interface • Dual independent FC ports
• 4-Gigabit FC data-transfer rates
• 800 MB/sec. maximum full-duplex throughput per channel
• Supports all FC topologies: direct fabric, arbitrated loop and point-to-point
• ANSI Fibre Channel: FC-PH, FC-FCP, FC-AL, FC-AL2, FC-PLDA, FC-FLA
• Flash ROM for easy field upgrades
• FC Class 3 Support
• Local management and diagnostics
• Buffer Credits: 8 @ 512 Bytes; 8 @ 2KB
• Advanced Data Streaming (ADS TM ) Technology
Advanced FC Capabilities • Supports SNIA HBA API
• Supports Windows FDMI and WMI
• Supports Target and Initiator modes
• Backward compatible with 2-Gb and 1-Gb Fibre Channel
Host Bus Specifications • x4 mechanical and x4 electrical PCI Express interconnect
• Supports PCI Express Base Spec 1.0a
• Supports PCI Express CEM Spec 1.0a
• PCI Express to PCI/PCI-X Bridge spec 1.0
External Connectivity • Easy-to-install full height connection bracket; low-profile bracket included in Finished Goods packaging
• External LEDs for on-line and speed status for each channel
• Two (2) pluggable optical LC SFP connectors included
Software Specifications
Driver Support • Windows Server 2003, 2008, XP, Vista, 7
•
Novell Netware 6.5
• Red Hat Linux (2.4 and 2.6 kernel)
•
Solaris 9 & 10
• SUSE Linux (2.6 kernel)
•
Free BSD
• Mac OS X (10.4.x - 10.6.x)
• VMware ESX Server 3.5
Agency Approvals
Safety and Environmental • FCC Rules, Part 15, Class B
• CE Mark: CISPR 22:2002/EN55022:2002, Class B
Environmental & Physical Specifications
Dimensions • Conforms to PCI Express Low Profile form-factor specifications
• Length 5.600”
• Height 2.712”
Operating Environment • Temperature: 0-45° C (32°-113°F)
• Humidity: 5 - 95% non-condensing
Storage Environment • Temperature: -40°-70°C (-40°-157°F)
• Humidity: 5 - 95% non-condensing
Power • 12V @ 0.4A max
• 3.3V @ 1.5A max
Airflow • 100 lf/m (min) recommended
Optical Cabling • 50/125µm up to 150m @ 4-Gb
• 50/125µm up to 300m @ 2-Gb
• 50/125µm up to 500m @ 1-Gb
Ordering Information
Model Number • CTFC-42ES-0R0 (RoHS)
RoHS Compliant Yes
Celerity FC-42ES
Host Adapter
Celerity FC-42ES
