Page 21

21
DISPLAY CABINET HEATED
P/N 1010772 Rev. D 12/13
Item Part
Description
Qty.
No.
REPLACEMENT PARTS – DCH-300/320 (continued)
1 7000367
Front Glass Assy.
1
2 0020676
Inner Lamp Housing Weldment
1
0020675
Inner Lamp Housing Weldment
Mfg. No. 9500553
3 0010706
Resistor Assembly - 120V
1
0010644
Resistor Assembly - 230V
1
4 0502850
Housing, Lamp
1
0502895
Housing, Lamp
Mfg. No. 9500553
5 9020469
Display Rack (optional)
1
6 7000444
Sliding Door Assembly
2
7000975
DCH Mirrored Doors Replacement Kit
1
(Mfg. No. 9500551 ONLY)
7 0501869
Support, Center Pan
2
8 0504354
Crumb Tray
1
(Mfg No. 9500554 & 556 Only)
9 0501866
Water Tray
2
Except for Mfg No. 9500554 & 556)
10 0502172
Shield, Heat
3
11 0021317
Control Panel Weldment
1
12 7000346
Temperature Control Display,
150°F-165°F (66°C-74°C)
1
7000345
Temperature Control Display,
100°-165°F (38°-74°C)
1
13 4010151
Switch, Rocker 25A-125V
1
4010137
Switch, Rocker 25A-250V
1
14 0900143
Glass, Side
2
15 0020702
Heat Sink Assy.
1
16 4010199
Transformer 120VAC/12VAC
1
4010187
Transformer 230VAC/12VAC
1
17 7000652
Relay, Solid State
1
18 7000136
Terminal Block-3 Pole (Incl. #50 & 65)
1
19 4060341
Terminal Block-8 Pole
2
20 0504070
Glass Retainer (see Note 1)
21 0011717
Top Cap Assembly** RH (see Note 1)
1
0011718
Top Cap Assembly** LH (see Note 1)
1
22 2100185
Upper Door Track
1
23 2100186
Lower Door Track
1
24 0501946
Grill, Blower
1
25 0700451
Power Cord w/Plug,
1
NEMA 5-20P 120 V
0700453
Power Cord w/Plug, CEE 7/7
1
26 020K108* Gasket Kit, Bottom
1
27 0503976
Lamp, Bulkhead
1
29 4060360 Lampholder
8
30 4060359
Lamp, Night - 120V, 10 Watts
8
31 0900152
Display Panel (Black Outline)
1
0900181
Display Panel (Clear)
1
32 0900174
Transparency Holder
1
33 0900153
Diffuser Panel (white)
1
34 0501860
Frame, Display
1
35 400K123 Motor, Blower 120V Incl. #71
2
(Except Mfg. No. 9500554 & 556)
4000194
Blower Motor Mfg. No. 9500553
1
36 0200155
Magnetic Strip
2
37 5040028
Base Hinge Assy.
1
38 4030304
Heating Element, 120V, 500 Watts
3
4030239
Heating Element 230 Volts 825 Watts
3
39 7000369
Thermistor Kit
1
40 0501865
Duct Access Cover
1
41 0502556
Deflector, Heat
1
42 4060252
Bulb-Quartz Halogen 100W
2
43 4060189
Bulbholder, Quartz
4
44 0800229
Guard, Lamp
1
0800224
Guard, Lamp Mfg. No. 9500553
45 0502866
Cover, Lamp Bracket
2
48 040K251 Strain Relief Kit.
1
040K315 Strain Relief Kit (Mfg. # 9500553)
1
46 0502865
Bracket, Lamp Housing
2
50 306P101* Nut, Hex, #6-32, SS
1
51 306P105* Screw, #6-32 x 1/2, SS
1
52 306P130* Nut, Hex, KEPS, #6-32
1
53 308P103* Screw, #8-32 x 1/4,
6
54 308P124* Screw, #8-32 x 1/2,
1
55 308P127* Screw, #8-32 x 5/16, SS
1
56 308P143* Nut, Hex, KEPS, #8-32
1
57 308P144* Screw, #8-32 x 1/4, #6 Head
2
58 308P159* Thumbscrew, #8-32 x 11/32
1
59 310P146* Nut, Hex, KEPS, #10-32
1
60 310P110* Screw, #10-32 x 1/2, SS
4
61 310P123* Screw, #10-24 x 1/2, SS
1
62 040P111* Snap Bushing
2
63 308P105* Screw, #8-32 x 1/2, SS
2
64 308P151* Screw, #8-32 x 5/16”
1
65 306P123* Screw, #6-32 x 7/8”
1
66 2180179
Side Glass Nylon Stopper
1
67a 0021478
Pan Adapter Insert (Optional)
1
(slope version)
67b 002K897 Pan Adapter Insert (Optional)
1
(non-slope version)
69 0501966
Diffuser, Water Tray
2
70 213K103 Full size pan 2-1/2” deep (optional)
1
71 7000174
Blower Cage Bearing & Grommet Kit
1
(Except Mfg. No. 9500554 & 556)
Item Part
Description
Qty.
No.
* Only available in packages of 10
** LH/RH is determined by viewing front of curved glass panel.
NOTE 1: If the existing 2 Top Glass Retainers (item #20) ARE NOT rubber coated, it is recommended that you replace them along with
the 2 Top Cap Assemblies (item #21) with Glass Hardware Kit #7000368. This kit consists of:
•
2 rubber coated Glass Retainers (P/N 0504070)
•
1 Top Cap Assembly (RH) (P/N 0011717)
•
1 Top Cap Assembly (LH) (P/N 0011718)
•
2 Nylon Slide Side Glass Stoppers (P/N 2180179)
•
2 Thumbscrews (P/N 3080159)
•
Installation Instructions (P/N 1010828)
