DISPLAY CABINET HEATED
16
P/N 1010772 Rev. D 12/13
1 7000365 Front Glass Panel Assy.
1
2 0021057 Inner Lamp Housing Weldment
1
3 0011107 Resistor Assy.
1
4 0503046 Housing, Lamp
1
5 0011102 Rear Door Assy. (Incl. #6, 7, 57, 58) 1
6 2110139 Hinge, Lift-Off
2
7 2100145 Knob, Cover
1
8 0503294 Crumb Tray (some models)
1
9 0503038 Water Tray (some models)
1
10 0502172 Heat Shield
1
11 0021315 Control Panel Weldment
1
12 7000346 Temperature Control Display,
150°F-165°F (66°C-74°C) DCH-100
1
7000345 Temperature Control Display,
100°-165°F (38°-74°C), DCH-120
1
13 4010151 Rocker Switch, Power On/Off 120 VAC 1
14 7000645 Side Glass Replacement Kit
1
15 0503948 Heat Sink Assy.
2
16 4010199 Transformer, 120V/12V
1
17 7000652 Relay, Solid State
1
18 7000136 Terminal Block, 3-Pole
1
(Incl. #47 & 60)
19 4060341 Terminal Block, 8-Pole
1
20 0504070 Retainer, Glass (
see Note 1) 2
21 0011718 Top Cap Assy., LH** (
see Note 1) 1
0011717 Top Cap Assy., RH** (
see Note 1) 1
22 0502866 Cover, Lamp Housing Bracket
1
23 0502865 Bracket, Lamp
1
25 0700463 Power Cord w/Plug, NEMA 5-15P
1
26 020K110 Gasket Kit, Bottom
1
27 0503990 Lamp, Bulkhead (Mfg# 9500512 only) 1
0503275 Lamp, Bulkhead
1
28 4060360 Candelabra Lamp Holder
4
30 4060359 Lamp, 120V, 10 Watt
4
31 0900216 Diffuser Panel (White)
1
32 2070120 Nipple, 1/8 NPT x 3/8
1
33 0900215 Display Panel (clear)
1
34 0021056 Display Frame Weldment
1
0021321 Display Frame Weldment
1
(MFG. # 9500512 only)
35 0503033 Display Frame
1
36 0200202 Magnetic Strip
1
37 5040036 Base Hinge Assy.
1
38 4030305 Heating Element, 120V 1400 Watts
1
39 7000369 Thermistor Replacement Kit
1
40 0503037 Duct, Access Cover
1
42 4060252 Bulb, Quartz Halogen, 100 Watt
1
43 4060189 Bulb, Holder, Quartz
2
44 0800316 Guard, Lamp
1
45 040K251 Strain Relief w/Locknut
1
47 306P101* Nut, Hex, #6-32, SS
1
48 306P105* Screw, #6-32 x 1/2, SS
1
49 306P130* Nut, Hex, KEPS, #6-32
1
50 308P103* Screw, #8-32 x 1/4
6
51 308P124* Screw, #8-32 x 1/2, One-Way
1
52 308P127* Screw, #8-32 x 5/16, SS
1
53 308P143* Nut, Hex, KEPS, #8-32
1
54 308P144* Screw, #8-32 x 1/4, #6 Head
2
55 308P159* Thumbscrew, #8-32 x 11/32
1
56 310P146* Nut, Hex, KEPS, #10-32
1
57 310P110* Screw, #10-32 x 1/2, SS
4
58 310P123* Screw, #10-24 x 1/2, SS
1
59 040P111* Snap Bushing
2
60 306P123* Screw, #6-32 x 7/8
2
61 308P151* Screw, #8-32 x 5/16”
1
62 0503044 Diffuser, Water Tray (some models)
1
63 400K123 Blower Kit 120V (some models)
1
Incudes #66
64 0501946 Blower Grill (some models)
1
65 2180179 Side Glass Nylon Stopper
2
(see Note 1)
66 7000174 Blower Cage Bearing/Grommet Kit
1
67 7000106 Display Rack (Optional)
1
Item Part
Description
Qty.
No.
Item Part
Description
Qty.
No.
REPLACEMENT PARTS – DCH-100/120
* Only available in packages of 10.
** LH/RH is determined by viewing front of curved glass panel.
NOTE: If the existing 2 Top Glass Retainers (item #20)
ARE NOT rubber coated. It is recommended that you
replace them along with the 2 Top Cap Assembly (item
#21) with Glass Hardware Kit #7000368.
This kit consists of:
• Two (2) rubber coated Glass Retainer (P/N 0504070)
• One (1) Top Cap Assembly (RH) (P/N 0011717)
• One (1) Top Cap Assembly (LH) (P/N 0011718)
• Two (2) Nylon Side Glass Stoppers
(P/N 2180179)
• Two (2) Thumbscrews (P/N 3080159)
• Installation Instructions
