DISPLAY CABINET HEATED
18
P/N 1010772 Rev. D 12/13
REPLACEMENT PARTS – DCH-200/220 (continued)
1 7000366 Front Glass Panel Assy.
1
1
1
1
2 0020675 Inner Lamp Housing Weldment
1
1
1
1
3 0010706 Resistor Assy., 120V
1
1
-
-
0010644 Resistor Assy., 220V
-
-
1
1
4 0502895 Housing, Lamp
-
-
1
1
5 9020459 Display Rack (Optional)
-
-
-
-
6 7000443 Sliding Door Assy.,
Clear Glass
1 1 1 1
7000445 Sliding Door Assy.,
Mirrored, Glass
(optional)
- - - -
7 0501820 Support, Center Pan
1
1
1
1
9 0503293 Crumb Tray (some models)
-
-
-
-
10
0503283
Heat
Shield
1 1 1 1
11 0021453 Control Panel Weldment
1
1
1
1
12 7000346 Temperature Control Display,
150°F-165°F (66°C-74°C) DCH-200
1
-
-
-
7000345 Temperature Control Display,
100°-165°F (38°-74°C), DCH-220
-
1
1
1
13 4010151 Rocker Switch, Power On/Off (120V)
1
1
-
-
4010137 Rocker Switch, Power On/Off (250V)
-
-
1
1
14 7000645 Side Glass Replacement Kit
2
2
2
2
15 0020702 Heat Sink Assy.
1
1
1
1
16 4010199 Transformer, 120V/12V
1
1
-
-
4010187 Transformer, 240V12V
-
-
1
1
17 7000652 Relay, solid state.
1
1
1
1
18 7000136 Terminal Block, 3 Pole (incl. #50 & 67)
1
1
1
1
19 4060341 Terminal Block, 8 Pole
2
2
2
2
20 0504070 Retainer, Glass (see Note 1)
2
2
2
2
21 0011718 Top Cap Assy., LH** (see Note 1)
1
1
1
1
0011717 Top Cap Assy., RH** (see Note 1)
1
1
1
1
22 2100183 Door Track, Upper
1
1
1
1
23 2100184 Door Track, Lower
1
1
1
1
24 0501946 Grill, Blower (some models)
1
1
-
-
25 0700451 Power Cord w/Plug, NEMA 5-20P 120V
1
1
-
-
0700453 Power Cord w/Plug, CEE 7/7 240V
-
-
1
1
26 020K107 Gasket Kit, Bottom
1
1
1
1
27 0503291 Lamp, Bulkhead (some models)
1
1
-
-
0503771 Lamp, Bulkhead (some models)
-
1
1
1
29 4060360 Candelabra Lamp Holder
6
6
6
6
30 4060359 Lamp, 120 v/10 Watt
6
6
6
6
31 0900151 Diffuser Panel (white)
1
1
1
1
32
0900173
Transparency
Holder
1 1 1 1
33 0900150 Display Panel (black outline) Optional
1
1
-
-
0900180 Display Panel (clear) Optional
-
-
-
-
0900244 Display Panel (blue outline)
-
1
1
1
34 0501797 Display Frame
1
1
1
1
35 400K123 Blower Motor, 120 Volt (some models) Incl #69
1
1
-
-
4000194
Blower
Motor
1
36
0200154
Magnetic
Strip
2 2 2 2
37 5040027 Base Hinge Assy.
1
1
1
1
38 4030324 Heating Element, 120V, 1400 Watts
1
1
-
-
Item Part
Description
Qty.
Qty.
Qty.
Qty.
No.
DCH-200 DCH-220 DCH-220 DCH-220
120 V
120 V
230 V
Mfg. # 9500533
* Only available in packages of 10
** LH/RH is determined by viewing front of curved glass panel.
