OPERATOR’S MANUAL
- ALAMO INDUSTRIAL®
To the Owner/Operator/Dealer
- BOOM ARM MOWER
Alamo Industrial Division is willing to provide
one (1) AEM Mower Safety Practices Video
TABLE OF CONTENTS
- General Safety Instructions and Practices
- Operator Safety Instructions and Practices
- Connecting & Disconnecting Implement Safety Instructions & Practices
- Equipment Operation Safety Instructions and Practices
- Maintenance and Service Safety Instructions and Practices
- Transporting Safety Instructions and Practices
- Concluding Safety Instructions and Practices
Decal Location
- 1. D377 1 MULTI Multi- Hazard Boom Safety Book
- 2. 03200347 1 REFLCTR SMV
- 1. 00769736 1 WARNING Use/Repair Shield & Guards
- 2. 00769737 2 DANGER Cutting Blades/Thrown Objects
- 3. 02725100 1 LOGO NAME BOOM AXE
- 4. 02925100 1 IMPORTANT Genuine Parts, Rotary
- 5. 02967827 1 DANGER Multiple Hazard, Rotary (*) (Mower
- 6. 02967867 1 DANGER Safety Gate Operation
- 7. 02970883 1 SIZE 50"
- 8. 00757139 2 LOGO ALAMO Industrial
- 9. 2738332 1 REFLECT Red Oblong Reflector
- 10. 2738333 1 REFLECT Yellow Oblong Reflector
- 11. 02979551 1 LOGO Alamo Ind. Sq. Green
- SAFETY SECTION
- Decal Description
- Federal Laws and Regulations
  - INTRODUCTION SECTION
ALAMO INDUSTRIAL MAVERICK BOOM MOWER
OPERATING INSTRUCTIONS
- 1. OPERATOR REQUIREMENTS
- 2. GETTING ON AND OFF THE TRACTOR
  - 2.1 Boarding the Tractor
  - 2.2 Dismounting the Tractor
- 3. STARTING THE TRACTOR
- 4. CONNECTING ATTACHING HEADS TO THE BOOM
  - 4.1 Connecting Mower Head Hydraulics
- 5. PRE-OPERATION INSPECTION AND SERVICE
- 6. OPERATING THE BOOM JOYSTICK CONTROL
- 7. DRIVING THE TRACTOR AND IMPLEMENT
- 8. OPERATING THE BOOM UNIT AND ATTACHED HEAD
- 9. TRACTOR, BOOM, AND ATTACHED HEAD STORAGE
- 10. TRANSPORTING THE TRACTOR AND IMPLEMENT
  - 10.1 Transporting on Public Roadways
  - 10.2 Hauling the Tractor and Implement
    - OPERATION SECTION
    - MAINTENANCE SECTION
Service of Spindle Housing (FIGURE Mnt-0006)
Start up Procedure
- 1. Read all safety instructions. Decals on the Machete Boom warn you of particular and multiple hazards. Many decals are attached close to part of the Machete Boom where there is a possible hazard. Read and make sure you understand the safety message...
- 2. Before operating, read all the safety and operating instructions in the Operators Manual for both the tractor and mower.
- 3. When the hydraulic tank has been filled and the mower unit properly assembled, the unit should be started up. NOTE: Make sure that no materials, tools, or jacks, have been left under the mower head. Make sure the front and rear of the mower are pr...
- 4. Start the tractor and idle at a slow engine speed until oil is being pumped.
- 5. Engage the Cutter Control Valve at low engine PTO Speed and run the mower slowly for a short period until all air is removed from the hoses. Keep all persons WELL CLEAR of mower since Blades can THROW OBJECTS with great velocity for a considerable...
- 6. With the area clear of any ground and overhead obstructions, work each cylinder on the boom one at a time, several times, to expel any air in the Hoses and Cylinders.
- 7. Run the Mower Head for 5 minutes. While the tractor is idling, blocked, wearing protective clothing and eye protection, CAREFULLY check for leaking hydraulic fittings, hoses and ports at this point with a piece of cardboard,DO NOT USE YOUR HAND! I...
- 8. Check the fluid level in the Hydraulic Tank on the Tractor, and add oil if required. As the air has been forced out of the Cylinders and Hoses, it goes into the Hydraulic Tank and reduces the oil level. Check your Tractors Operators Manual for the...
Timber Cat Head
Buzzbar Head
- Belt Tension Adjustment (Figure Mnt-B-0010)
- Lubrication:
- Flail Axe Head
- Grass Flail Head
- MOTOR & COUPLING INSTALLATION
- TAPER BUSHING & SHEAVE INSTALLATION
General Information on Flail Mower Vibration
FLAIL MOWERS
INFORMATION BULLETIN NO. 5
- The cutter shaft will run out of balance if:
Spindle Service Procedure 02960553B and 02960553C
- 1. Remove blade bar or pan.
- 2. Remove hydraulic motor.
- 3. Remove spindle assembly from mower deck.
- 4. Drain remaining lubricant from housing.
- 5. Using a 3/16" cape chisel, bend out the staking indentations on each side of the bearing adjusting nut. To do this, place the chisel in the groove and parallel to the shaft. Drive the chisel downward until the indentation is free of the shaft and ...
- 6. Using the same chisel, straighten the tang on the lockwasher (if equipped with a lockwasher). NOTE: The lockwasher will not be installed during assembly if the spindle uses the staked adjusting nut.
- 7. Remove bearing adjusting nut and lockwasher (if equipped). Discard these parts. They are not re- usable. Install a new adjusting nut when assembling.
- 8. Screw the original blade bar bolts into the flange of the spindle shaft until they contact the bearing ring (see Figure Mnt-B-0015).
- 9. In a clockwise pattern, rotate each bolt 1/4 turn (see Figure Mnt-B-0015). Continue turning the bolts 1/4 turn at a time (maximum of 3 turns), until the special shank bolts (P/N 02964353) will thread into the spindle.
- 10. Remove the original bolts and replace them with the shank bolts. Screw the shank bolts in until they contact the bearing ring.
- 11. In a clockwise pattern, rotate the bolts 1/4 turn at a time until the spindle is free from the housing.
- 12. Remove the seal retaining ring from the housing using a flat screwdriver or similar tool.
- 13. Remove the seal and bearing.
- 14. A punch or similar tool can be used to remove the bearing cups from the housing if the cups are not to be re-used.
- Cleaning
  - 1. Clean housing and all related parts thoroughly and dry.
  - 2. Protect parts from contamination.
- Inspection
- Assembly
  - 1. Place upper bearing cones in bearing oven.
  - 2. Seat bearing cups (outer races) in housing using a press and proper installation tools in good condition. CUPS MUST BE FULLY SEATED. If bearing cup cocks in bore and seizes, do not continue to assemble spindle.
  - 3. Lubricate lower bearing cone with LPS.
  - 4. Coat the outside of the seal with silicone and install the lower bearing, seal, and retaining ring into the housing, using the correct seal installer.
  - 5. Place a light film of silicon or permatex on the inside diameter of the bearing ring and seat the ring on the spindle shaft, using the proper tool and press.
  - 6. Lightly lubricate the lip of the seal.
  - 7. Using the 2-3/4" tubing to prevent the cup and cone from contacting each other, press the spindle shaft through the lower bearing and seal. Make sure the bearing is seated against the bearing ring.
  - 8. Place Locktite on threads of the bearing adjusting nut (flange nut).
  - 9. Using gloves, install the heated upper bearing cone on the shaft immediately and push it all the way against the cup. Lubricate the bearing with LPS.
  - 10. Install the bearing adjusting nut. Tighten the nut until the spindle shaft can not be turned. Loosen the nut 1/ 4 turn. Place a soft, clean cloth over the top of the spindle assembly. Place an aluminum block over the end of the spindle shaft and ...
  - 11. Remove the cloth, being careful not to allow any contamination into the spindle. Tighten the nut until a rolling torque of 16-21 inch-pounds is reached. (If the seal was not lubricated, add 10 inch-pounds).
  - 12. Stake the nut with a blunt, round nosed punch. Do not tear the nut.
  - 13. Install the grease fitting into the hole in the center of the housing (between the bearings) and fill the housing with EP#2 grease, stopping when the lubricant covers the upper bearing (approximately 11 oz.).
  - 14. Install the breather plug in the top hole.
  - 15. Install spindle in mower deck and assemble in reverse order. Torque the blade bar or pan bolts to 400 ft- lbs. Torque motor to spindle bolts to 85 ft-lbs. Torque spindle to deck bolts at 175 ft-lbs.
- Lubrication Information
- MOWER HEAD:
- ROTARY HEAD:
- Hydraulic Oil, Filters, and Components
- TANK FILL
- Blades
Hardware
- Cylinder Rod Maintenance
Proper Torque for Fasteners
