Applications
The VR6010 is designed for high current draw applications, like giant-scale airplanes with multiple high current draw servos. Spektrum’s model VR6010
6-volt 10-amp regulator allows the use of 2-cell lithium or 5- to 8-cell NiCd and NiMH receiver packs to be used to power your onboard radio system. A
single VR6010 regulator provides 10-amps continuous current (16 amp peaks) making it ideal for most high current draw applications. For heavy duty
applications two VR6010’s can be used to provide 20-amps continuous and up to 32-amps peak power. The VR6010 is ideal for use with Spektrum’s
AR9100 PowerSafe receiver and comes pre-wired with EC3 connectors.
Features
• Fail-on soft switch prevents radio loss due to switch failure
• Pre-wired with EC3 connectors ready to install with AR9100 PowerSafe
• Heavy-duty 16 gauge power leads
• Cooling fan provides additional current handling capability
• Convenient mounting lugs
• Two can be used with the AR9100 PowerSafe for up to 20-amps
continuous current
Note: When the battery is connected to the regulator a low current drain of less than 1mAh occurs even when the switch is turned off. If the system is going to
be stored for any length of time it is important that the battery(s) be disconnected from the regulator to prevent over discharge.
Note: It is normal for the regulator to become warm during heavy operation.
SPECIFICATIONS
Note: Consult your servo manufacturer’s specifications for maximum allowable voltage.
Batteries
Spektrum offers a line of 5-cell NiMH and 2-cell LiPo battery packs that are pre-wired with EC3 connectors ready to plug into your VR6010 regulator.
SPMB1350LP LiPo Receiver Pack 1350mAh
SPMB2000LP LiPo Receiver Pack 2000mAh
SPMB4000LP LiPo Receiver Pack 4000mAh
SPMB6000LP LiPo Receiver Pack 6000mAh
SPMB1650NM 1650mAh 6.0V NiMH Receiver Pack
SPMB2150NM 2150mAh 6.0V NiMH Receiver Pack
SPMB2700NM 2700mAh 6.0V NiMH Receiver Pack
SPMB4500NM 4500mAh 6.0V NiMH Receiver Pack
Spektrum VR6010 6.0-Volt, 10-Amp Regulator Instructions
Type:
Voltage Input:
Output Voltage:
Continuous current @ 8.4V:
Peak Current:
Dimensions WxLxH:
Weight:
10-amp linear voltage regulator
6- to10-volts (5- to 8-cell NiCd/ NiMH or 2-cell LiPo)
6.0-volts
10-amps
16-amps
40 x 30 x 30mm 1.57 x 1.18. x 1.18 in (less mounting tabs)
50 grams/ 1.8 oz
