Transmitter functions – Spektrum DX6 User Manual
Page 7
7
SPEKTRUM DX6 • TRANSMITTER INSTRUCTION MANUAL
EN
Function
1
Handle
2
Throttle Spring Tension
Adjustment (Mode 2,4)
Gimbal Stick Tension
Adjustment
4
Mode Change
5
Left Rear Grip
Function
6
Audio Jack
Charge Port For use with
optional Lithium Ion Battery
8
Battery Cover
9
Trainer Port
10
Right Rear Grip
Function
11
Gimbal Stick Tension
Adjustment
12
Mode Change
Throttle Spring Tension
Adjustment (Mode 1,3)
TRANSMITTER FUNCTIONS
F
C
D
6
6
8
9
10
12
1
13
4
11
7
2
3
5
3
13
7
