9
ASSEMBLY
FIG. 1
1/4 X 3/4 HEX BOLT
HITCH ASSEMBLY
1/4" HEX LOCK NUT
5/16 HEX NUT (2)
CLUTCH CABLE
MOUNTING ANCHOR
3/8 HEX LOCK NUT
3/8 FLAT WASHER
3/8 X 2-3/4 HEX BOLT
3/8 FLAT WASHER
#10 SCREW (2)
CABLE CLIP (2)
1/4 X 7-1/2
HEX BOLT
CLUTCH LEVER
RED WIRE
SCREW (4)
BATTERY
COVER
TERMINAL ACCESS DOORS
1/4 X 3/4 HEX BOLT &
1/4 HEX NUT (SEMS)
BATTERY HOLD DOWN
1/4 X 7-1/2 HEX BOLT
PLASTIC NUT
+
-
BLACK WIRE
REAR QUADRANT
