Agri-Fab 45-03621 User Manual
Page 23
23
ITEM PART NO.
DESCRIPTION
48.
HA115321
SCREW 5/16-18 X 5/16 SOC. SET
50.
43555
WASHER 7/16" LOCK
51.
HA181668
BOLT 7/16-20 X 1-1/4 HEX HEAD
53.
25265
COVER, FRONT DRIVE
55.
43182
BOLT 5/16-18 X 3/4 HEX HEAD
56.
47810
NUT 5/16-18 HEX NYLOCK
57.
25264
COVER, REAR DRIVE
58.
HA23732
TANK GASOLINE
59.
HA24317
PLATE FUEL TANK
60.
HA163318
SCREW 1/4-14 X 7/8 TAPPING PAN HEAD
61.
HA23733
CAP GASOLINE TANK
62.
48837
HOSE FUEL TANK LONG
63.
392154
SPARK ARRESTOR KIT
64.
HA23792
CLAMP FUEL LINE
65.
HA9411666
SCREW #10-16 SELF TAPPING
66.
48095
PIPE
67.
48096
CAP
68.
HA24310
BRACKET ROLLER
69.
HA12138
ROLLER MOWER
70.
HA12315
DECAL DANGER (HAND)
71.
HA12314
DECAL DANGER
72.
HA24431
DECAL OPERATION/CAUTION
74.
HA126145
BOLT 1/2-13 X 7" HEX HEAD
75.
43982
PIN, CLEVIS 1/4" X 5/8"
76.
HA22981
BELT GUIDE
77.
HA24298
SPRING RETURN
78.
49156
ROD, CABLE GUIDE
79
47189
NUT 1/4-20 HEX NYLOCK
80.
44488
WHEEL BEARING
81.
HA23754
SOLENOID
82.
HA23749
STARTER SWITCH
83.
HA23750
SWITCH MOUNTING NUT
84.
HA23757
SWITCH COVER
85.
HA23752
KEY
86.
25286
PLATE, SWITCH MOUNTING
87.
49201
THROTTLE
88.
45040
SCREW, #10-24 X 1/2
89.
736-0722
LOCK WASHER, #10
90.
49198
BATTERY HOLD DOWN
91.
49199
BOLT, BATTERY
92.
49200
NUT, PLASTIC
93.
25287
BATTERY COVER
94.
48840
SCREW, 1/4-20 X 1/2 HEX HEAD
* Order engine repair parts from your nearest Briggs & Stratton
dealer.
ITEM PART NO.
DESCRIPTION
1.
HA24255
MOWER DECK
2.
HA24378
GUARD WHEEL
3.
HA23193
SCREW 3/8-16 X 1-1/4 THD. FORMING
4.
HA24292
BRACKET BELT GUIDE
5.
HA24293
ROD BELT GUIDE
6.
HA3090
PIN HAIR COTTER
7.
HA24294
V-BELT (B SEC. 60" O.C.)
8.
HA24295
CHANNEL CLUTCH LEVER
9.
45100
BOLT 1/2-13 X 4" HEX HEAD
10.
HA120396
WASHER 1/2 FLAT
11.
43262
NUT 1/2-13 HEX LOCK
12.
HA14232
WASHER FLAT
13.
HA24296
ROD CLUTCH LINK
14.
44101
PIN, COTTER 3/32" X 3/4"
15.
43081
WASHER FLAT 5/16" STD. WRT.
16.
HA24297
SPRING CLUTCH
17.
49165
CLUTCH CABLE ASSY
18.
25292
STRAP, CLUTCH ADJUSTING
19.
43661
BOLT, 1/4-20 X 1" HEX HEAD
20.
43012
BOLT, HEX 1/4-20 X 3/4"
21.
25262
BRACKET INTERLOCK MOUNTING
22.
HA23199
SWITCH INTERLOCK
23.
48115
NUT, HEX 1/2-13 JAM NYLOCK
24.
712-0121
NUT #10-24 HEX
25.
47078
SCREW #10-24 X 3/4"
26.
48840
SCREW 1/4-20 WASHER HEAD
27.
48298
CLIP
28.
HA24300
WHEEL MOUNTING BRACKET L.H.
29.
HA24301
WHEEL MOUNTING BRACKET R.H.
30.
HA4143
WASHER FLAT
31.
HA137258
PIN COTTER 3/16" X 1-3/4"
32.
46272
TIRE
33.
HA23229
CAP HUB
34.
HA24309
STRAP ADJUSTING
35.
HA6979
WASHER FLAT
36.
43020
BOLT 1/2-13 X 1-1/2 HEX HEAD
37.
43019
NUT 1/2-13 HEX JAM
38.
HA23220
PIN LOCATING
39.
47134
PIN HAIR COTTER .08" X 1.58"
40.
HA24311
CHAIN DEFLECTOR
41.
HA24312
ROD CHAIN
42.
HA24313
BRACKET CHANNEL
43.
HA9131
SCREW SELF THREADING
44.
25428
PLATE ENGINE MOUNTING
45.
280H070130E1* ENGINE, 14.5 HP
46.
HA24457
PULLEY
47.
HA3073
KEY 1/4" SQ. X 1"
the
fastest way to purchase parts www.speedepart.com
42" ROUGH CUT TRAILMOWER - MODELS 45-03621 & 45-03622
