Parts List
To order parts, contact your Authorized Service Agent. Supply the model designation, serial number, part description, part number,
quantity, and when applicable, voltage and phase.
Key
Description
Part #
1
Water Fill Assembly
139396
2
Safety Valve
097005
3
Check Valve
004187
4
Pressure Gauge
170003
5
Trunnion Support Arm Assembly
137877
6
Kettle Body Assembly, No TDO 208V
Kettle Body Assembly, No TDO 240V
Kettle Body Assembly, No TDO 480V
Kettle Body Assembly, TDO 208V
Kettle Body Assembly, TDO 240V
Kettle Body Assembly, TDO 480V
140593
140594
140595
140596
140597
140598
7
Slight Glass
108554
8
Knob Thermostat
170229
9
Base and Pedestal Assembly
147855
10
Light, Red
116383
11
Pedestal Weldment
138107
12
Electrical Mount Assembly
138123
13
Tilt Switch
002982
14
Contactor
148102
15
Transformer, 208/240v/24v 40va
Transformer, 480v/24v 40va
137441
137694
16
Ground Terminal
129714
17
Terminal Block
003888
18
Fuse Holder
077854
19
Fuse, 3 Amp
077853
20
Water Level Board
122192
21
Pressure Switch
096963
22
Thermostat
009730
23
Water Level Probe
070178
Key
Description
Part #
24
Element, 208v 9.95kw
Element, 240v 8kw
Element, 480v 8kw
005977
005974
005980
25
Foot, Adjustable Bullet
013275
26
Handle, Crank
013617
27
Shaft, Handwheel
013624
28
Stand Cladding
139054
29
Leg Tube
147506
30
Left Frame Support
146999
31
Right Frame Support
137953
32
Inner Frame Support
137954
33
Rear Frame Support
146998
34
Short Frame Support
137955
35
Pedestal Cladding Assembly
138112
36
Gear Bore
013609
37
Worm Gear
012026
38
Bearing
009765
39
Bearing Housing
009762
40
Key 3/8”
001474
41
Set Screw
012060
X
Cover Skirt
139834
X
Cover, Side Pedestal
001464
X
Cover, Top Pedesta
138114
X
Cover, Lower Trunnion Support Arm
137863
X
Cover, Upper Trunnion Support Arm
137860
X
Overlay Operating Instructions
170011
X
Harness, Wire
148544
X
Harness, High Voltage
149942
X
Harness, Control
149943
X - Item not depicted/called out in drawing or photograph.
