Installing the Bridging Converter
24
Table 5 lists the possible settings of the DIP switches..
When setting the DIP switches, consider the following:
❑
Setting the Auto Neg DIP switch for the twisted pair port to ON or
OFF enables or disables Auto-Negotiation for the port. If you disable
Auto-Negotiation, be sure to set the DIP switches for the port’s speed
and duplex mode to match the speed and duplex mode of the end-node.
❑
If the end node connected to the twisted pair port is not using Auto-
Negotiation and has a fixed duplex mode of full-duplex, you must
disable Auto-Negotiation on the twisted pair port and set the speed
and duplex mode manually. Otherwise, a duplex mode mismatch will
result. For further information on this, refer to “Duplex Mode” on page
12.
❑
Disabling Auto-Negotiation on the twisted pair port also disables Auto
MDI/MDI-X and configures the port as MDI-X.
Table 5 DIP Switch Settings
DIP
Switch
Number
Port Setting Position Description
1 2 Speed (Mbps) Up
Down
The twisted pair port operates at 10 Mbps.
The twisted pair port operates at 100 Mbps.
2 1 Duplex Mode Up
Down
The fiber optic port operates in half-duplex
mode.
The fiber optic port operates in full-duplex
mode.
3 2 Duplex Mode Up
Down
The twisted pair port operates in
half-duplex mode.
The twisted pair port operates in
full-duplex mode.
4 2 Auto Neg Up
Down
Auto-Negotiation on the twisted pair port is
OFF.
Auto-Negotiation on the twisted pair port is
ON.
