ASUS P7P55-M 2-17
2.5.2 Chipset
The Chipset menu allows you to change the advanced chipset settings. Select an item then
press to display the submenu.
Memory Remap Feature [Enabled]
Allows you to enabled or disable the remapping of the overlapped PCI memory above the
total physical memory. Enable this option only when you install 64-bit operating system.
Configuration options: [Disabled] [Enabled]
2.5.3 Onboard Devices Configuration
HDA Controller [Enabled]
Allows you to enable or disable the high definition audio controller.
Configuration options: [Enabled] [Disabled]
Front Panel Type [HD Audio]
Allows you to select the front panel type. If High Definition Audio Front Panel used,
please set HD Audio mode. Configuration options: [AC97] [HD Audio]
Onboard LAN [Enabled]
Allows you to enable or disable the onboard LAN controller.
Configuration options: [Enabled] [Disabled]
Onboard LAN Boot ROM [Disabled]
Allows you to enable or disable the boot ROM in the onboard LAN controller. This item
appears only when the Onboard LAN item is set to Enabled. Configuration options:
[Disabled] [Enabled]
Onboard IDE Controller [Enabled]
Allows you to enable or disable the onboard IDE controller. Configuration options: [Enabled]
[Disabled]
1394 Controller [Enabled]
Allows you to enable or disable the 1394 controller.
Configuration options: [Disabled] [Enabled]
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Parallel Port Address [378]
Allows you to select the Parallel Port base addresses. Configuration options: [Disabled] [378]
[278] [3BC]
Parallel Port Mode [Normal]
Allows you to select the Parallel Port mode.
Configuration options: [Normal] [Bi-Directional] [EPP] [ECP]
ECP Mode DMA Channel [DMA3]
Appears only when the Parallel Port Mode item is set to [ECP]. This item allows you to
set the Parallel Port ECP DMA. Configuration options: [DMA0] [DMA1] [DMA3]
