P7P55-M specifications summary
ASUS exclusive
overclocking features
SFS (Stepless Frequency Selection):
- Internal Base Clock tuning from 133 MHz up to 500MHz
at 1MHz increment
- PCI Express frequency tuning from 100MHz up to
160MHz at 1MHz increment
Overclocking Protection:
- ASUS C.P.R.(CPU Parameter Recall)
Back panel I/O ports 1 x PS/2 keyboard/mouse combo port
1 x COM port
1 x IEEE1394
1 x LAN (RJ-45) port
8 x USB 2.0/1.1 ports
8-channel audio I/O ports
Internal I/O
connectors
3 x USB 2.0/1.1 connectors support additional 6 USB 2.0/1.1
ports
1 x IDE connector
6 x SATA connectors
1 x CPU fan/1 x Chassis fan connectors
1 x LPT connector
1 x Front panel audio connector
1 x S/PDIF Out connector
1 x 24-pin EATX power connector
1 x 4-pin ATX 12V power connector
1 x System panel connector
BIOS 16 Mb Flash ROM, AMI BIOS, PnP, DMI 2.0, WfM 2.0,
SM BIOS 2.5, ACPI 2.0a
Accessories 1 x Ultra DMA 133/100/66 cable
2 x Serial ATA 3.0Gb/s cables
1 x I/O shield
1 x User Manual
Support DVD Drivers
ASUS Utilities
ASUS Update
Anti-virus software (OEM version)
Form factor microATX form factor: 9.6 in x 8.6 in (24.4 cm x 21.8 cm)
* Specifications are subject to change without notice.
