AT-8324SX Quick Install Guide
7
Switch LEDs
Table 1 describe the functions of the LEDs on the Ethernet switch.
For information on troubleshooting the switch, refer to the AT-8324SX Fast
Ethernet Switch Installation Guide.
Table 1 Port and System Status LEDs
LED Condition Status
System
PWR On Switch is receiving power.
RPS On Redundant power is on and the RPS is in the
backup or active mode.
Off Redundant power is off or has failed.
MGMT On Agent is operational.
RJ-45 Ports
Link On Port has established a valid network connec-
tion.
Amber Valid 10 Mbps connection.
Green Valid 100 Mbps connection.
Flashing Port has been partitioned due to an abnormal
network condition, or manually disabled.
Activity 1
1. Use the MODE Select button to select LED display mode.
On Traffic is passing through the port.
FULL DUP 1 On Port has been set to full-duplex.
FLOW
1
On Flow control enabled.
Module Ports
STATUS On A module is installed in the slot.
ACT Flashing Traffic is passing through the port.
