Connectivity guidelines – Allied Telesis AT-BMGMT User Manual
Page 18
8
Connectivity Guidelines
Table 2 Console Port to 9-Pin COM Port on PC
Switch’s 9-Pin Serial Port
CCITT Signal
PC’s 9-Pin COM Port
1 DCD
----- DCD -----
1
2 RXD
<----- TXD -----
3
3 TXD
----- RXD ----->
2
4 DTR
----- DSR ----->
6
5 SGND
----- SGND -----
5
6 DSR
----- DTR -----
4
7 RTS
----- CTS ----->
8
8 CTS
<----- RTS -----
7
9 RI
----- RI -----
9
