DIP Switch Settings

SW 1 DIP Switches
The DIP switches in the SW 1 DIP switch set described in the following table allow you to
set the operating mode of the line card. For information about the operating modes as
well as Smart MissingLink and MissingLink, refer to the relevant management software
user’s guide.

“X” means that the DIP switch position can be ON or OFF.

SW 2 DIP Switches
The DIP switches in the SW 2 DIP switch set described in the following table allow you to
configure the MDI/MDI-X feature on the twisted pair port..

“X” means that the DIP switch position can be ON or OFF.

Twisted Pair Port Pinouts

The pinouts for the RJ-45 twisted pair port are shown in the following illustration.

The following table lists the RJ-45 pin signals when a twisted pair port is operating in the
MDI or MDI-X mode.

Warranty Information

The AT-CV10x Series (AT-CV101, AT-CV102, and AT-CV102/x Series) line cards have a
limited warranty of five years. Go to www.alliedtelesis.com/warranty for the specific terms
and conditions of the warranty and for warranty registration.

Specifications

Physical, Environmental, and Electrical Ratings
Dimensions (H x W x L)

(2.2 cm x 7.3 cm x 13.0 cm)
.855 in. x 2.89 in. x 5.1 in.

Weight

0.27kg (0.60 lbs.)

Operating Temperature

0° C to 40° C (32° F to 104° F)

Storage Temperature

-25° C to 70° C (-13° F to 158° F)

Operating Relative Humidity

5% to 90% (non-condensing)

Storage Relative Humidity

5% to 95% (non-condensing)

Operating Altitude Range

Up to 3,048 m (10,000 ft.)

Predicted MTBF (Telcordia SR332)

AT-CV101

1,020,000 hours

AT-CV102

890,000 hours

AT-CV102/1 1,020,000 hours
AT-CV102

1,020,000 hours

Power Consumption

5.7 Watts

Optical Output Power (dBm)

Receiver Power Sensitivity (dBm)

Electrical Safety and Emissions Statements

This product meets the following standards when installed in compliant host equipment.

Emissions

FCC Class A, EN55022 Class A, VCCI Class A, C-TICK, CE

Warning: In a domestic environment this product may cause radio interference in which

case the user may be required to take adequate measures.

Immunity

EN55024

Electrical Safety

UL60950 (

c

UL

us

), EN60950 (TUV), CSA22.2 No. 950

Copyright © 2007 Allied Telesis, Inc. All rights reserved.
No part of this publication may be reproduced without prior written permission from Allied
Telesis, Inc.

Operating Mode

DIP 1

DIP 2

DIP 3

DIP 4

Link Test (default)

OFF

OFF

OFF

X

Smart MissingLink (SML)

OFF

ON

ON

X

MissingLink (ML)

OFF

OFF

ON

X

Manufacturing Default Settings

OFF

OFF

OFF

OFF

Operating Mode

DIP 1

DIP 2

DIP 3

DIP 4

Auto MDI-X Enabled (default)

X

OFF

X

X

Auto MDI-X Disabled

X

ON

X

X

Manufacturing Default Settings

OFF

OFF

OFF

OFF

MDI Mode

MDI-X Mode

Pin

Signal

Pin

Signal

1

TX+

1

RX+

2

TX-

2

RX-

3

RX+

3

TX+

6

RX-

6

TX-

8

8

1

1

Line Card

Minimum

Maximum

Wavelength

Connector

AT-CV101

-20 dBm

-14 dBm

1310 nm

Dual ST

AT-CV102

-20 dBm

-14 dBm

1310 nm

Dual SC

AT-CV102/1

-15 dBm

-5 dBm

1310 nm

Dual SC

AT-CV102/2

-15 dBm

0 dBm

1310 nm

Dual SC

Line Card

Minimum

Maximum

AT-CV101

-31 dBm

-11 dBm

AT-CV102

-31 dBm

-11 dBm

AT-CV102/1

-34 dBm

-3 dBm

AT-CV102/2

-34 dBm

-3 dBm

U.S. Federal Communications Commission

Radiated Energy

Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to

Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference

when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in accordance with this instruction manual, may cause

harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause

harmful interference in which case the user will be required to correct the interference at his own expense.

Note: Modifications or changes not expressly approved of by the manufacturer or the FCC, can void your right to

operate this equipment.

Industry Canada

This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment

Regulations.

Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du

Canada.
