Twisted Pair Port Pinouts

The pinouts for the RJ-45 twisted pair port are shown in the following illustration.

The following table lists the RJ-45 pin signals when a twisted pair port is operating in the
MDI or MDI-X mode.

Warranty Information

The AT-CV5M0x Management Card has a limited warranty of five years. Go to
www.alliedtelesis.com/warranty for the specific terms and conditions of the warranty and
for warranty registration.

Specifications

Dimensions (H x W x L)

2.2 cm x 7.3 cm x 13.0cm
(.855 in. x 2.89 in. x 5.1 in.)

Weight

0.27 kg (0.60 lbs.)

Operating Temperature

0° C to 40° C (32° F to 104° F)

Storage Temperature

-25° C to 70° C (-13° F to 158° F)

Operating Relative Humidity

5% to 90% (non-condensing)

Storage Relative Humidity

5% to 95% (non-condensing)

Operating Altitude Range

Up to 3,048 m (10,000 ft.)

Predicted MTBF (Telcordia SR332)

1,320,000 hours

Input Supply Voltage

5V DC, 3.3 V DC

Maximum Input Current

1.15 A (5V DC), 0.86 A (3.3V DC)

Power Consumption

9.6 Watts maximum

MDI Mode

MDI-X Mode

Pin

Signal

Pin

Signal

1

TX+

1

RX+

2

TX-

2

RX-

3

RX+

3

TX+

6

RX-

6

TX-

8

8

1

1

Electrical Safety and Emissions Statements

This product meets the following standards when installed in compliant host equipment.

Emissions

FCC Class A, EN55022 Class A, VCCI Class A, C-TICK, CE

Warning: In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.
Immunity

EN55024

Electrical Safety

UL60950 (

c

UL

us

), EN60950 (TUV), CSA22.2 No. 950

U.S. Federal Communications Commission

RADIATED ENERGY

Note: This equipment has been tested and found to comply with the limits for a Class A digital device

pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with this instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own expense.

Note: Modifications or changes not expressly approved of by the manufacturer or the FCC, can void

your right to operate this equipment.

Industry Canada

This Class A digital apparatus meets all requirements of the Canadian Interference-Causing

Equipment Regulations.

Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel

brouilleur du Canada.

Copyright

© 2007 Allied Telesis, Inc. All rights reserved.

No part of this publication may be reproduced without prior written permission from Allied
Telesis Inc.
