10

Network Service Module

613-000610 Rev C

LEDs and What They Mean

The following LEDs report operations and faults on NSMs:

“AT-AR041 and AT-AR042 LEDs” on page 10

“AT-AR048 and AT-AR048-B LEDs” on page 11

“Switch and Router LEDs” on page 11

The AT-AR040 and AT-AR040-B NSM units do not have independent LEDs. See

“Switch and Router LEDs” on page 11

for information about related LEDs found on

the base switch or router.

PIC LED descriptions can be found in the Port Interface Card Hardware Reference,
which can be downloaded from

www.alliedtelesis.com/support/software

.

AT-AR041 and AT-AR042 LEDs

The following table describes LEDs on the AT-AR041 and AT-AR042 NSMs.

LED

State Function

Active

Green

Lit when the BRI has successfully completed the
exchange of INFO 1 and INFO 2 signals, and INFO
3 and INFO 4 signals are present on the link. This
means the ISDN interface is correctly connected
to a working NT device.

Off

There is no connection to the ISDN, or the ISDN
has deactivated the connection.

Data

Amber

For on-demand ISDN, lit when there is a call up
over the respective B (data) channel.

For permanent circuits, lit when HDLC packets are
being exchanged between the switch or router and
another TE end system device (normally another
switch or router) over the respective B channel.

Flashing Amber

For on-demand ISDN, flashing when data is being
exchanged.

Off

For on-demand ISDN, Off when there is no active
connection or when continuous data exchange is
occurring.

For permanent ISDN circuits, Off when no data
exchange is occurring.
