Installing an AT-SPSX SFP Transceiver
To install an AT-SPSX transceiver, perform the following
procedure:
Caution
The transceiver can be damaged by static electricity.
Be sure to observe all standard electrostatic discharge
(ESD) precautions, such as wearing an antistatic wrist
strap, to avoid damaging the device.
1. Remove the transceiver from the shipping package and
store the packaging material in a safe place.
2. Slide the transceiver into the SFP slot.
If you are connecting the fiber optic cable to the SFP at
this time, continue to step 3. Otherwise, stop here.
3. Remove the dust cover.
4. Connect the fiber optic cable to the transceiver.
For information about the transceiver port LEDs, refer to
the appropriate hardware installation guide.
