Expansion Modules
12
For the latest list of approved SFP+ fibre transceivers and Direct Attach copper
modules, contact your authorised Allied Telesis distributor or reseller. See the
most current revision available of the XEM datasheet (document number 617-
000034) for further information about which SFP+ fibre transceivers modules
and Direct Attach copper modules are approved for use with the XEM-2XS.
Caution Allied Telesis recommends waiting 30 seconds after hot swapping
any XEM before resuming normal operations. The switch must fully complete
the bootup process before you can hot swap any XEM. Also ensure the XEM
fastening thumbscrews are fully tightened. If you are unsure about correct
procedures, contact your authorised Allied Telesis distributor or reseller.
SFP+ Green An SFP+ fibre transceiver or a Direct Attach copper
module is installed and enabled.
Amber The port is disabled because either a non SFP+ fibre
transceiver or a disabled Direct Attach copper module
is installed.
Amber
flashing The SFP+ fibre transceiver is not ready or has a fault.
Direct Attach copper modules cannot indicate a fault.
Off An SFP+ fibre transceiver or a Direct Attach copper
module is not installed.
LED State Description
