PCM-9588 User Manual 4
1.3.1.3 Chipset (ICH6M)
I/O:
1.3.1.4 Other (chipset)
LPT 1
RS-232 4
RS-232/422/485 2 (Default RS-422/485, RS-232 by optional request)
K/B 1
Mouse 1
USB 6 x USB2.0
Audio AC97, Line-in, Line-out, Mic-in, speaker out (R/L)
GPIO 16-bit general purpose input/output
IRDA 115 kbps (optional by request) shared from COM2
South Bridge
Controller Hub Intel ICH6M
PCI Compliant
Supports 33MHz PCI 2.2 specification
Supports for 64-bit addressing on PCI using DAC protocol
PCI Bus
! PCI masters
PCI to ISA bridge (ITE8888G)
10/100 LAN(RTL8100CL-LF)
Other Feature
! 6 USB 2.0 ports, 480MB/s
! 2 Serial ATA(150MB/s)
! Power Management
! FWH interface to Flash BIOS
! 6 COM ports, 4 x RS-232; 2 x RS-232/422/485 Signal (Support
Auto flow control).
COM1, 2, 3, 4: RS-232
COM5, 6: RS-422/485 (Default RS-422/485, RS-232 by optional
request)
LAN
Chipset
LAN 1: Realtek RTL8100CL-LF for 10/100 Giga LAN(RTL8110SCL-LF)
optional (preserve circuit) Preserve UL60601 design only on LAN1
IEEE Compliant Fully compliant with IEEE 802.3, IEEE 802.3u and IEEE 802.3ab
LAN LED LED1: Off for 10M LAN, Green or 100M LAN
LED2: On for Link, flash for active,
Disable LAN
through BIOS
Yes
Wake on LAN Yes (S1 only)
Boot from LAN Yes (S5 only)
LED connector pin header - with TX/RX LED signal
Audio
Chipset
AC97 Audio
Codec ALC203
Rear panel output Line-In, Line-out, Mic-In
Amplifier
Yes. (2.2W)
Hardware Monitor
Chipset
LPC I/O for onboard alarm
