13
NOTE : This is a normally opened starter cut arrangement, and when power is removed from the
security system, the starter disable feature will remain operational, and the vehicle will not start.
Audiovox does not recommend using the Orange w/ White trace wire to interrupt anything but the
starting circuit of the vehicle.
Blue w/ White Trace Wire: (-) Instant Trigger Zone 1
This is a instant on ground trigger input intended for the connection of optional triggering devices. The
ground trigger output wire of motion detectors, microwave detectors, or glass break detectors, can be
connected to this Blue w/ White Trace trigger input wire.
Lt Gray/Black Wire : DELAYED 300 mA PULSED OUTPUT / CHANNEL 5
The light gray/blackwire pulses to ground via an independent RF channel from the keychain transmitter. This
is a transistorized, low current output, and should only be used to drive an external relay coil.
WARNING: Connecting the light blue/green to the high current switched output of trunk release circuits,
some remote start trigger inputs, will damage the control module.
Connect the llight gray/blackwire to terminal 86 of the AS - 9256 relay (or equivalent 30 A automotive relay)
and wire the remaining relay contacts to perform the selected function of channel 5.
White/Black Wire : DELAYED 300 mA PULSED OUTPUT / CHANNEL 6
The lWhite/Black wire pulses to ground via an independent RF channel from the keychain transmitter. This
is a transistorized, low current output, and should only be used to drive an external relay coil.
WARNING: Connecting the White/Black wire to the high current circuits, will damage the control module.
Connect the White/Black wire to terminal 86 of the AS - 9256 relay (or equivalent 30 A automotive relay) and
wire the remaining relay contacts to perform the selected function of channel 6.
Light Blue/Black Wire : DELAYED 300 mA PULSED OUTPUT / CHANNEL 7
The light blue/black wire pulses to ground via an independent RF channel from the keychain transmitter.
This is a transistorized, low current output, and should only be used to drive an external relay coil.
WARNING: Connecting the light blue/black to the high current circuits, will damage the control module.
Connect the light blue/red to terminal 86 of the AS - 9256 relay (or equivalent 30 A automotive relay) and wire
the remaining relay contacts to perform the selected function of channel 7.
Black/Gray Wire: DIESEL WAIT TO START INPUT
The Black/Gray Wire, when connected to the wire that get + 12 volts during the glow plug preheat stage will
delay the starter output until this wire drops the 12 volts. In other words, in a Diesel vehicle with glow plug
preheat circuit, when the ignition is turned on, the vehicle will not crank until the glow plugs are hot enough
to fire the atomized fuel oil when injected into the cylinder. By connecting this wire to the glow plug + 12 volt
wire, when the remote start unit activates the ignition one output, the glow plug output also activates. The
remote start sees the Black/Gray Wire with positive voltage and waits for this to go inactive( drop the 12
volts) before activating the starter motor. If this wire is not used or you have difficulty accessing the glow
plug preheat circuit, you may elect to utilize the Diesel timed output as specified in Remote Start feature
selection #9. NOTE: If Black/Gray Wire is used, it will override or negate any setting of feature #9.
WIRING THE 4 PIN AUXILIARY OUTPUT HARNESS
The auxiliary 4 pin connector provides low current outputs to control various functions in the vehicle during
different stages of the Remote Start unit's operation. Understanding these outputs and the time in which
they occur will allow you to determine if they are needed for the particular vehicle you are working on as well
as how to use them.
Light Green W/BlackTrace Wire: Pulsed Ground Output Before Start
The Light Green W/BlackTrace wire will provide a 1 second 300 mA pulsed ground output 1.5 second before
the remote start unit activates as well as when the transmitter is used to disarm the system. Typical use for
this output would be to disarm a factory theft deterrent system to prevent false triggering of the factory alarm
when the remote start unit engages or when the system is used to unlock the doors.
NOTE: This output can be selected to operate like the door lock output as set in alarm feature setting #1 by
selecting feature #7 on.
Light Blue Wire: Pulsed Ground Output After Start
The Light Blue Wire will provide a 1 second 300ma pulsed ground output after the vehicle is started under
control of the remote start unit. Typically this wire will be used to re-lock the vehicle doors if the doors
unlock automatically when the factory anti-theft system is disarmed. This wire will also activate when the
transmitter is used to alm/lock the system.
Black w/ Red Trace Wire: Pulsed Ground Output After Shutdown
The Black w/ Red Trace wire will provide a 1 second 300 mA pulsed ground output after the remote start unit
shuts down. This output will occur regardless of whether the circuit times out or is manually terminated.
Typically this output will be used to re-lock the vehicle doors if the doors unlock automatically when the
ignition circuit transitions to off.
