Model APS 685

Installation Manual

4 Channel Remote Start / Keyless Entry System

Installation Instructions

This Unit Is Intended For Installation In Vehicles With

12 Volt Negative Ground Electrical Systems,

Gasoline or Diesel With True Tach Reference

And Automatic Transmissions Only.

Kit Contents

APS-685 Control Module

(2) - 4 Button Anti Code Grabbing Transmitters

4 Channel Code Learning Receiver

External Superheterodyne Antenna/Receiver

(1) - Multi Pin Input/Output Harness

(1) - Six Pin Power Harness

(1) - Four Pin Auxiliary Harness

(1) - Two Pin I/O Harness

(1) - Accessory 2 Pin Connector

(1) - 2 Pin Door Lock Harness

(2) - 30 Amp In-line Fuse Holders With Fuses

(1) - Control Switch

(1) - Programming Switch

(1) - Ring Terminal

(4) - 1/2" Long Screws

(1) - Pin Switch

(1) - Remote Start Warning Label

(1) - Literature Package
