10
English
Connections
Basic Features
How to Navigate Menus
Before using the TV, follow the steps below to learn how to
navigate the menu and select and adjust different functions.
S.MODE
MEDIA.P HDMI
RETURN
ΕΧΙΤ
INFO
SLEEP DUAL
P.MODE P.SIZE E.SAVING
SOURCE
CH LIST
A B C D
TTX/MIX
2
3 4
1
1 MENU button: Displays the main on-screen menu.
2 ENTER E / Direction button: Move the cursor and
select an item. Confirm the setting.
3 RETURN button: Returns to the previous menu.
4 EXIT button: Exits the on-screen menu.
How to Operate the OSD (On Screen Display)
The access step may differ depending on the selected menu.
1
MENU m The main menu options appear on
the screen:
Picture, Sound, Channel, Setup,
Input, Application, Support.
2
▲ / ▼ Select an icon with the ▲ or ▼
button.
3
ENTER E Press ENTER E to access the
sub-menu.
4
▲ / ▼ Select the desired submenu with
the
▲ or ▼ button.
5
◄ / ► Adjust the value of an item with the
◄ or ► button. The adjustment in
the OSD may differ depending on
the selected menu.
6
ENTER E Press ENTER E to complete the
configuration.
7
EXIT e Press EXIT .
Changing the Input Source
Source List
Use to select TV or other external input
sources such as DVD / Blu-ray players /
cable box / STB satellite receiver connected
to the TV.
■ TV / Ext. / AV / Component / HDMI1/DVI
/ HDMI2 / USB
✎
In the Source List, connected
inputs will be highlighted.
✎
Ext. always stay activated.
SOURCE
Edit Name
■ VCR / DVD / Cable STB / Satellite STB / PVR STB /
AV Receiver / Game / Camcorder / PC / DVI PC /
DVI Devices / TV / IPTV / Blu-ray / HD DVD / DMA:
Name the device connected to the input jacks to make
your input source selection easier.
✎
When connecting an HDMI/DVI cable to the HDMI IN
1(DVI) port, you should set to DVI PC or DVI Devices
mode under Edit Name.
