ALIGNMENT AND ADJUSTMENTS
3
NO
Error Code
(Diagnostic Code
Error Image)
Description Corrective Action
11 dS
Door is detected as open while it is
trying to lock the door.
Go to “Quick Test Mode” and then do
Door Lock/Unlock Test
12 tE
Abnormal high/low temperature or
resistance (Thermal sensor or PBA
resistance).
Go to “ Board Input Test” and check
Water Temperature. Check loose
or pinched wires. Replace PCB or
thermistor.
13 3E Motor problem
restart the cycle if the code reappears,
call for service
14 Hr
Heater Relay Failure (No Heater Relay
Check Signal)
Replace PCB
15 nF1
The hot/cold water hose connection is
not correct.
Please connect the hot/cold water
hose connection correctly.
16 2E
Voltage for motor control bus is over
or under specified limit.
Replace PCB
17 Suds
Suds is detected during the washing
session. (“SUdS” is not an error. If the
washer is in suds period, “SUdS” will
light up instead of remaining time.)
Guide a user to reduce amount of
detergent usage.
18 AE
Communication error between SUB
PBA and MAIN PBA
Check Main PBA, SUB PBA & Wire-
harness. Replace PCB
19 8E1 Front MEMS sensor problem
Check MEMS Sensor, MANI PCB &WIRE
Harness
20 8E2 Rear MEMS sensor problem
Check MEMS Sensor, MANI PCB &WIRE
Harness
To avoid risk of electrical shock, personal injury or death; disconnect power to washer
before servicing, unless testing requires power.
WARNING
