Samsung SR-T03BEBB User Manual
Page 6
8
7
Connect the IDE cable (with 40 pins) connected to the hard disc
to the interface port.
(Place the cable so that where the red wire is goes to pin No. 1)
Master Drive
Slave Drive (Select the SL jumper)
PRI 1
SEC 1
Master drive :(Select the MA jumper)
Master drive
Slave drive :(Select the SL jumper)
(Select the MA jumper)
(Select the SL jumper)
Master drive
Master drive :(Select the MA jumper)
PRI 1
SEC 1
