Appendix
Specifications
Specifications for the CN-6000 are given in the table, below:
Function Specification
Connectors CPU Port 1 x SPDB-15 F - KVM Link
Console
Ports 1 x 6 pin mini-DIN F - Keyboard
1 x 6 pin mini-DIN F - Mouse
1 x HDB-15 F - Video
LAN 1 x RJ-45 Receptacle
Power 1 x 3 Pronged Receptacle
Reserved 1 x RS-232 M (DB9)
LEDs Power 1 (Blue)
Link 1 (Green)
10/100 Mbps 1 (Green/Orange Dual Color)
Video Up to 1280 x 1024 @ 60 Hz
Protocols 10BaseT Ethernet; 100BaseT Fast Ethernet;
TCP/IP
Operating Temperature 0 - 50
o
C
Storage Temperature -20 - 60
o
C
Humidity 0 - 80% RH
Housing Metal
Weight 0.5 Kg
Dimensions (L x W x H) 20 x 8 x 2.5 cm
2003-11-14
43
