Preparations
1
1 Preparations
1.2 Attaching the Stand
Before assembling the product, place the product down on a flat and stable surface so that the screen
is facing downwards.
Insert the Stand Connector into the Stand in the direction shown
by the figure.
Check if the Stand Connector is firmly connected.
Turn the connecting screw at the bottom of the stand fully so that
it is completely fixed.
Place a soft cloth over the table to protect the product and place
the product onto the cloth so that the front of the product is facing
downwards.
Hold the main body of the product with your hand as shown by
the figure. Push the assembled stand into the main body in the
direction of the arrow as shown in the figure.
