English - 4
Install the Stand
Components
When installing the stand, use the provided components and parts.
Stand (depending on the model) Guide Stand Screws
C
D
x4 (M4 X L12)
x4 (M4 X L8)
B A 1 EA 1 EA
3
4
(Correct assembly) (Incorret assembly)
D
(M4 X L8)
x4
Side View
B
A
Rear
Front
C
(M4 X L12)
x4 Top View
DO NOT USE
CHEMICALS
DO NOT USE
GREASE
DO NOT USE
OIL
ATTENTION
1 2
✎
Place a soft cloth over the table to protect the TV,
and then place the TV on the cloth screen side down.
✎
Insert the Stand Guide into the slot of TV bottom
side.
➢ Make sure to distinguish between the front and back of each component when assembling them.
➢ Make sure that at least two persons lift and move the TV.
Caution
