Connection Jacks (Side)
You can connect an A/V component that is used only occasionally, such as a camcorder or
video game. (For information on connecting equipment, see page 17.)
1 AUDIO Input
Connect audio signals from a camcorder or video game.
2 VIDEO Input
Connect a video signal from a camcorder or video game.
3 Headphone
Connect a set of external headphones to this jack for private listening.
•
Please be sure to match the color coded input terminals
and cable jacks.
